Download
datablad
Approvals
CE
Compliance with standards
IEC-EN62208
Operating temperatures
-35° ÷ +80°C
Protection degree
IP67 - IP69 (IEC-EN60529)
Protection against impact
IK09 (IEC-EN62262)
Enclosure material
PA Polyamide - glass fiber reinforced
Gasket material
TPE thermoplastic elastomer
Screw material
Stainless steel AISI 304
Screw type
Torx T15 slotted head type
Enclosure thickness
3,5mm
Tightening torque
0.8 ÷ 1.2Nm (7.1÷10.6 Lb-in)
Protection against electric shock
Class II (IEC-EN61140)
Halogen-free
yes
Combustion behaviour
HB (UL94)
Combustion behaviour
650°(IEC-EN60695-2-11)
Fitted for outdoor application
yes
Warranty period
18 months
technische tekeningen
Drukknopkast in PA + glasvezel 70x90x63, zonder gaten, geel
080T0709-6G
specificaties
Rubriek
080T0709-6G
Omschrijving
Drukknopkast in PA + glasvezel 70x90x63, zonder gaten, geel
Kleur
Giallo RAL1003 / Grigio RAL7035
Prijslijst €
Verpakking - pz
1
Gewicht - gr
132,00
Beschikbaarheid
Producibile in 5 giorni
Omschrijving
85381000
GTIN
8052878074135
